Tellium LED Head
Product Features
- From the brand formerly known as Tech Lighting
- High-tech display head that combines simplicity with practical technology
- Precise light beam that directs light where you want it
- This item is made of natural brass. It is a living finish that will patina and warm with age which adds richness. If it gets an uneven patina or spots, a brass cleaner can restore the finish
- Compatible with the Monorail and Monopoint systems by Tech Lighting
- Monopoint version - The LED Driver is housed within the junction box. (L. 3.05" | W. 1.5" | H. .98")
Lamping
Includes 12 volt 7 watt, 750 total delivered lumens, 3000K, LED module. Dimmable with Low-Voltage electronic or magnetic dimmer (based on transformer). Provided with 20°, 40° and 60° beams spread lenses. The inrush current is reduced so that the Tellium LED head can be loaded to a standard 70% of the transformer's maximum rated wattage. Additionally, the dimming performance will be more stable and have a lower minimum dim level than the existing integrated LED heads. 360° head rotation and 90° pivot. Integrated lens holder accommodates one MR16 sized lens or louver (sold separately).
Ordering Information
| 700 | System TLML | Length (A) | Finish | Lamp | ||||||||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
Note. MP includes 4" Round Flush Canopy. Aged Brass is not available for Two-Circuit Monorail. For custom stem lengths, please contact the Quotes Department.
700
Job Name
Notes
TLML
Tellium LED Head
Specifications
| Primary Material | Aluminum |
| Shade Material | Aluminum |
| Net Weight | 1 lbs |
| Height | 2.3in |
| Width | 3.8in |
| Length | 2.3in |
| Beam Spread | |
| Up light / Down Light / Both? | |
| Wet Listed | |
| Damp Listed | |
| Dry Listed | Yes |
| Min. Hanging Height | 12in |
| Max Hanging height | 12in |
| Total Cord Length | |
| Sloped Ceiling Adaptable? | N/A |
| General Listing | ETL Listed |
| Includes |
Lamping Specifications
| Led Lamp | Integrated LED | Non Led | No Lamp | |
|---|---|---|---|---|
| Delivered Lumens | 750 | |||
| Watts | 7 | |||
| Max Wattage Per Bulb | 7W | |||
| Input Voltage/ Dimming Type |
12V ELV, MLV 120V ELV, MLV |
|||
| CCT | 3000K | |||
| CRI | 90 CRI | |||
| LED Lifetime | ||||
| L70 | >50000 | |||
| Average Bulb Hours | ||||
| Field Serviceable LED | ||||
| Lamp Base | Integrated LED | |||
| Lamp Shape | Integrated LED | |||
| Lamp Included? | True | |||
| Warranty** | 5 Years |
* Dimming information available at www.techlighting.com/Downloads#dimming
** Visit techlighting.com for specific warranty limitations and details.
T20 / T24 / JA8 Information
| Integrated LED | Replacement LED Lamp | No Lamp * | |
| This product can be used to comply with California Building Energy Efficiency Standards 2016 Title 24 Part 6 / JA8. | Yes | ||
| This product can be used to comply with California Appliance Efficiency Standards 2016 Title 20 and may be shipped to and sold in California. | Yes |
* If a light fixture or component does not include a lamp or light source, it is the responsibility of the customer to select a lamp that meets the T24 and T20 requirements.
