Vex 5 Outdoor Wall
Product Features
- From the brand formerly known as Tech Lighting
- For up- and down-light option, light direction is independently controlled. Symmetric or asymmetric beam angles can be set from 10° - 120° with simple tool-free adjustment.
- Angle markers ensure consistent and precise aiming and adjustment from fixture to fixture.
- Die-cast aluminum structure, powder coat finish, and stainless steel hardware for robust durability in harsh elements. appropriate for commercial use.
- Wet listed, IP65 (International Protection rating indicating resistance to dust and water. suitable and safe for commercial use).
- The LED Driver is housed within the junction box. (L. 3.3" | W. 1.6" | H. 1")
Lamping
To view all available finish options, please visit techlighting.com
Ordering Information
| 700OWVEX | CRI | Color Temp | Length (A) | Finish | Voltage | ||||||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
700OWVEX
Job Name
Notes
Vex 5 Outdoor Wall
Specifications
| Primary Material | Aluminum |
| Shade Material | |
| Net Weight | 2.4 lbs |
| Height | 4.6in |
| Width | 4in |
| Length | 4.6in |
| Wet Listed | Yes |
| Damp Listed | |
| Dry Listed | |
| General Listing | ETL Listed |
| Includes |
Lamping Specifications
| Led Lamp | Integrated LED | Non Led | No Lamp | |
|---|---|---|---|---|
| Delivered Lumens |
291.0 554 |
|||
| Watts |
9.2 18.7 |
|||
| Max Wattage Per Bulb | ||||
| Input Voltage/ Dimming Type |
Universal 120V-277V 0-10, ELV, TRIAC 120V 0-10, ELV, TRIAC |
|||
| CCT |
2700K 3000K |
|||
| CRI | 90 CRI | |||
| LED Lifetime | ||||
| L70 | >60000 | |||
| Average Bulb Hours | ||||
| Field Serviceable LED | ||||
| Lamp Base | Integrated LED | |||
| Lamp Shape | Integrated LED | |||
| Lamp Included? | True | |||
| Warranty** | 5 Years |
* Dimming information available at www.techlighting.com/Downloads#dimming
** Visit techlighting.com for specific warranty limitations and details.
T20 / T24 / JA8 Information
| Integrated LED | Replacement LED Lamp | No Lamp * | |
| This product can be used to comply with California Building Energy Efficiency Standards 2016 Title 24 Part 6 / JA8. | Yes | ||
| This product can be used to comply with California Appliance Efficiency Standards 2016 Title 20 and may be shipped to and sold in California. | N/A |
* If a light fixture or component does not include a lamp or light source, it is the responsibility of the customer to select a lamp that meets the T24 and T20 requirements.
